Trane 3.5–5 Ton 42000–60000 BTU A4MX 4 Way Cased Coil A4MXC4260AC3HA

Trane 3.5–5 Ton 42000–60000 BTU A4MX 4 Way Cased Coil A4MXC4260AC3HA To complete a highly efficient system, the Trane 4 Ton 42000 – 60000 BTU A4MX Four Way Convertible, Upflow, Downflow, Horizontal Left & Right Cased Coil for Split-System Heat Pump & Air Conditioner A4MXC4260AC3HA is a perfect choice.
5 1 5 1
0 / 5 5

Your page rank:

$800.00 $785.00
available in stock
Quantity
Description

To complete a highly efficient system, the Trane 4 Ton 42000 – 60000 BTU A4MX Four Way Convertible, Upflow, Downflow, Horizontal Left & Right Cased Coil for Split-System Heat Pump & Air Conditioner A4MXC4260AC3HA is a perfect choice.

Quantity
Product Number: A4MXC4260AC3HA Category: Tags: , , , , , , , GTIN: A4MXC4260AC3HA

Square Installments

A cased coil is one of the most important parts of your HVAC system as it performs a deciding role on how well your HVAC system performs. To complete a highly efficient system, the Trane 4 Ton 42000 – 60000 BTU A4MX Four Way Convertible, Upflow, Downflow, Horizontal Left & Right Cased Coil for Split-System Heat Pump & Air Conditioner A4MXC4260AC3HA is a perfect choice.

The Four Way Convertible Cased Coil performs at an efficiency of about 15 SEER. In addition to this, it maintains a high standard of physical durability as well, with an all-aluminum coil and foil-faced thermally insulated body. Furthermore, the compact body design makes it easy to install as well. Together, these features make the A4MX Cased Coil the right choice for any efficiency conscience homeowner.

Features of Trane 4 Ton 42000 – 60000 BTU A4MX Four Way Convertible Cased Coil A4MXC4260AC3HA

  1. Indoor coils with an efficiency of about 15 SEER.
  2. All aluminum coil design for better exchange and more durability.
  3. Easy installation, with upflow, downflow or horizontal applications.
  4. Advanced foil-faced thermal insulation is used on the body, for better cleaning, reduced servicing time during AC maintenance and better temperature retention.

Specifications of Trane 4 Ton 42000 – 60000 BTU A4MX Four Way Convertible, Upflow, Downflow, Horizontal Left & Right Cased Coil A4MXC4260AC3HA

Cased Coil Specifications

Tonnage 3.5, 4, 5 Tons
Capacity 42000 – 60000 BTU
Coil Type Cased
Configuration Upflow, Downflow, Horizontal Left & Right
Refrigerant control Piston
Lineset Connection Type Sweat

Maximum Airflow

Upflow 1850 CFM
Horizontal Left 1850 CFM
Downflow 1750 CFM
Horizontal Right 1750 CFM

Cased Coil Dimensions

Gas Connection 7/8 In
Liquid Connection 3/8 In
Drain Connection 3/4 In
Coil Height 30 In
Coil Width 21 In
Coil Depth 20 In

Cased Coil Weight

Coil Weight 76 lbs.
Coil Shipping Weight 85 lbs.
